Deploying Console into Air-Gapped Environments

When deploying management console into an air-gapped environment, you need to ensure that the console has access to the required images.

Docker Images​

You can download the images and upload them into internal docker registry.

docker pull quay.io/deepfenceio/deepfence_worker_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_server_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_ui_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_file_server_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_agent_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_cluster_agent_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_router_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_redis_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_kafka_broker_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_postgres_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_neo4j_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_compliance_scanner_ce:2.5.8
docker pull quay.io/deepfenceio/deepfence_telemetry_ce:2.5.8
export IMAGE_REPOSITORY=127.0.0.1:5000

docker tag quay.io/deepfenceio/deepfence_worker_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_worker_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_server_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_server_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_ui_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_ui_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_file_server_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_file_server_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_agent_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_agent_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_cluster_agent_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_cluster_agent_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_router_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_router_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_redis_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_redis_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_kafka_broker_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_kafka_broker_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_postgres_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_postgres_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_neo4j_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_neo4j_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_compliance_scanner_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_compliance_scanner_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_telemetry_ce:2.5.8 ${IMAGE_REPOSITORY}/deepfence_telemetry_ce:2.5.8
docker tag quay.io/deepfenceio/deepfence_agent_ce:fargate-2.5.8 ${IMAGE_REPOSITORY}/deepfence_agent_ce:2.5.8
export IMAGE_REPOSITORY=127.0.0.1:5000

docker push ${IMAGE_REPOSITORY}/deepfence_worker_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_server_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_ui_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_file_server_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_agent_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_cluster_agent_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_router_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_redis_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_kafka_broker_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_postgres_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_neo4j_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_compliance_scanner_ce:2.5.8
docker push ${IMAGE_REPOSITORY}/deepfence_telemetry_ce:2.5.8

Now follow the documentation here to deploy the console using the internal registry.

env IMAGE_REPOSITORY=127.0.0.1:5000 docker compose up -d

ThreatIntel database​

You can download the latest ThreatIntel database and upload it in Settings page.

Scan history & Threat Intel
Scan history & Threat Intel
